2 Way Motorized Valves
Application: Used to control the open/close of central
air-conditioning fan coil cold water or hot water, in order to achieve the purpose of the control room temperature.
Feature: Motorized valve consists of two parts electric actuator and the valve.
Funtion: Actuator can be installed close to the wall of plane design, small space
Description
Xiamen Hysen Control Technology Co., Ltd. is one of the most credible manufacturers and suppliers of 2 way motorized valves in China, also supports customized service. Please feel free to wholesale discount 2 way motorized valves from our factory.
Production Introduction
2 Way Motorized Valves are motor-driven valves that use electricity to control the flow of liquid or gas. The valve is opened or closed via a motor-driven, adjustable mechanical device. The motor is connected to the drive shaft, which turns the valve stem. The stem has a rotating disc at the end, which is attached to the valve body. This disc controls the opening and closing of the valve. They are commonly used for controlling flow in heating and cooling systems, water systems, and gas systems.
Professional production of motorized actuator by claw pole hysteresis synchronous motor as the driver, motor connected to the thermostat, the valve closed by a spring retun.Valve does not work in a normally closed state,when need to work, provided by a thermostat open signal to make the actuator motor is connected to the power and the rotation, open the valve,when the valve opens, the biggest actuator motor blocked work status, cold water or hot water into the fan line,thus to provide indoor air conditioning or heating, when indoor temperature reached set value, the thermostat instruction actuator motor power, under the action of the valve in the spring shut down automatically, thus truncation fan coil cold water or hot water. Across the valve closed or open, make indoor temperature always stay in the thermostat setting temperature value.
Product Specifications
Power: | 220VAC 50Hz |
Power consumption: | ≤5W |
Valve body nominal pressure: | 1.6MPA |
Alowed pressure: | ≤0.13MPA |
Applicabie medium. | cold water,hot water |
Valve size: | DN15,DN20,DN252 way,3 way |
Environmental temperature: | 0~40℃ |
Product Feature
Motor large output torque.can achieve the best when the valve opens, prompting the flowthrough the large flow, smallrevert.
torque, closed without resistance, blocking water completely, and do not leak.
Buit-in stainless steel valve spring, not easy fatigue, and can completely shut down by the water, increase the electric vave life.
Actuator connected to the valve, by means of screw without any tools, installation and dismanting can be quickly.
Product Application
Fitted on manifold or small valves for the control of warm-water (floor) heating systems used in commercial buildings,residential buildings,light industrial buildings...
Normally closed switch for control of small valves or PDM.
Perform the stability control of the control switch closed-loop valve.
Installed in the water collection circuit and thermostatic valve line.
When the electric actuator is powered off, the valve is closed.
Packing Listing
1 * Thermostat
1 * Actuator
FAQ
Q1: Accepted Payment Term:
A1: T/T, Credit Card, PayPal, Western Union etc...
Q2: What can you buy from us?
A2: hermostats, temperature controller, actuator, thermostatic radiator valve etc
Q3: Accepted Delivery Terms:
A3: FOB,CNF,DAP,EXW etc...
Q4: Who are we?
A4: Xiamen Hysen Control Technology Co., Ltd. is a well established manufacturer which located in the Xiamen, Fujian. Southeast of Province. P. R. China. Our company is built on the principles of making quality products and providing reliable service.
